PRINCESS F62 - 2022

Length overall (incl. pulpit): 62ft 11in (19.17m)
Length overall (excl. pulpit): 62ft 1in (18.92m)
Beam: 16ft 0in (4.87m)
Draft: 4ft 9in (1.46m)
Displacement approx.: 28,857kg (63,619lbs)
Fuel capacity: 715 gal/858 US gal/3,250l
Water capacity (incl. calorifier): 132 gal/159 US gal/603l



Twin Volvo D13-1000 (2 x 1000mhp)

Standard Equipment

Variable speed bow and stern thrusters with hold-function docking facility. (Note: Standard bowthruster is uprated to 170kgF and a 170kgf sternthruster is fitted)

Seakeeper Gyro Stabiliser (NG9) – Includes upper helm control via the chart plotter screens

(with dark grey waterline & black antifouling, hull & bathing platform fendering is white with stainless steel insert)

Silver Oak interior wood satin finish (galley and aft dinette floor is planked Light oak groove standard)

Forward saloon floor groove in oak

Aft Cabin Fit out (single berth with separate WC and shower)
Starboard cabin to have double berth conversion with powered sliding mechanism on inboard berth

Stools for use at dinette or forward saloon area (x2) (NB locker below companionway stairs will accommodate 2 stools)

Interior styling includes
S class quilting detail to helm seats with contrast piping and panelling(Princess S62)
Exterior styling includes
Cockpit seat backrest surround painted in Oyster Grey metallic
Teak step nosings upgrade (to include transom and steps to side deck, when side deck option is selected)
Exterior lighting upgrade package (includes additional deck level lights (11) to illuminate side deck and foredeck area and deck level spot lights (2) on garage door to illuminate bathing platform deck)
Underwater transom lights (4 Lumishore SMX 53 White)
Underwater lighting to aft hull sides (x2 per side Lumishore SMX 53 White)
Foredeck sunbed cushions with adjustable headrests
Exterior upholstery with S class quilting with contrast panelling and piping – MET ICE with MET STORM
Flybridge console area, flybridge wetbar and cockpit servery to be finished in Oyster Grey metallic

Carrara White galley worktop

Bathroom worktops are in Carrara White Solid Surface (gloss finish)
with Carrara White floors



Note : The S60 has an up/down electro hydraulic transom platform with 450Kg SWL capacity fitted as standard, however if a tender is being carried in the garage (up to 3.3m) it is recommended that the combined
weight of the garage & bathing platform loading is no greater than 500Kg when underway
Teak laid side decks, foredeck and coachroof walkthrough
Teak laid sportbridge deck
Teak coffee table (with deck mounted fixing point) for foredeck
Electric stern rope handling winches (2)
Electro-hydraulic telescopic passerelle (3.5m) with automatic hand rails
Passerelle wiring – in order to be able to use the remote control when the main battery master switches are off, the passerelle is wired directly to the domestic batteries via an isolation switch on the main AC/DC panel
Passerelle to be wired via the master switch in addition to its own switch
Third station controls in cockpit (engine controls and emergency stops, thruster controls)
Electrically operated sliding roof over forward saloon area incorporating standard skylights with blinds
Electrically operated sun awning to aft end of cockpit (grey fabric)
Stainless steel anchor in place of standard (32Kg)
Additional 20m of 10mm anchor chain to give a total of 60 metres

An ONAN 11Kw/50Hz generator is fitted as standard
ONAN 17.5Kw/50Hz generator in place of standard (the 17.5Kw
generator is recommended if air conditioning is specified and has ample
reserve power for gyro stabilisers as well as all boat systems)

Multi sockets, in place of standard sockets (throughout craft)
“please note that as these sockets will take various plug types it is the
customers’ responsibility to ensure that the appliance being plugged in
matches the boats operating voltage. PYL cannot be held liable for
equipment damage that results from a mismatch of voltages”
(not for use in USA or Australia)
Dishwasher (drawer type) fitted in galley
Lava brick BBQ to sportbridge wetbar
Icemaker fitted in flybridge
Fit heated towel rail in bathroom (2 each – VIP)
Combination washer/dryer fitted in Master Stateroom lobby below
companionway stairs
Stern docking lights

Deck Saloon – 50″ UHD LED TV (on a powered lift) with Fusion Apollo
RA-770 with Wifi/DAB and external USB, Samsung BD-J5900 Blu-ray
player, 4 Focal 100 ICW5 speakers
Owners stateroom – 43″ UHD LED TV with Fusion MS-AV755
Radio/DVD/MP3 player with Bluetooth facility Cockpit – waterproof Fusion signature 7.7″ speakers and local control
(Fusion NRX-300) – linked to saloon
Sportsbridge – Fusion SRX-400 Radio/Wifi/Bluetooth with waterproof
Fusion signature 6.5″ speakers linked to saloon audio
Foredeck Speakers

Standard navigation equipment incorporates:
Raymarine Axiom XL16 (15.6″) multifunction colour display at both lower and upper helm positions and incorporating gps/chartplotter, log and echo sounder. Raymarine Evolution autopilot with P70Rs control
head also fitted at both helms. In addition engine instrumentation
(including fuel levels and fuel flow) is displayed on a separate 9″
multifunction displays at both helm positions
Raymarine Magnum HD colour radar, 4kW pedestal with 48″ open array
Second Raymarine Axiom XL16 (15.6″) colour multifunction display at lower helm
Raymarine i70s 4″ multifunction display at lower helm (for separate display and control of individual functions e.g. log and echo sounder)
Second Raymarine Axiom XL16 (15.6″) colour multifunction display at upper helm
Raymarine i70s 4″ multifunction display at upper helm (for separate display and control of individual functions e.g. log and echo sounder)
Rest of world version plotter
Raymarine 700 AIS Class B transponder interfaced with chartplotter and fitted with active AIS 100 aerial splitter
International VHF

Airconditioning/heating reverse cycle (82,000 BTU) suitable for
temperatures to 40°C (tropical)
With controls in all cabins and outlets in all areas (including bathrooms)
Recommended generator : 17.5Kw
Aft cabin air conditioning
Condensing unit 6,000BTU supplying 6,000BTU unit (with SMX control)
and separate outlet in toilet

Mosquito screens for all opening port lights

The standard holding tank (approx. 55 gallons / 250 litres) includes a
remote tank contents gauge. The toilet can discharge directly into the holding tank but also has the ability to discharge directly overboard via a Y valve fitted in the discharge line. The holding tank and has both dockside and manual overboard discharge facilities fitted as standard
Electric discharge
In addition to the manual overboard and dockside discharge facilities an electric overboard discharge system is fitted. The electric overboard discharge system incorporates an electric valve with timer. When the
pump is turned on a time delay allows the electric valve to open before the pump starts. When the pump is switched off the valve closes. This means the through hull seacock does not need to be opened/closed every time the pump is switched on. The through hull seacock is itself fitted
with a micro switch which prevents operation of the pump when it is closed. The electric valve has a manual override facility Aft cabin toilet to be connected into holding tank system

Fit reticulated foam to all standard exterior cockpit, foredeck &
sportbridge seating & aft sunpad in place of standard
Exterior Covers – Grey canvas
Bimini Top – Grey canvas
Additional charge for bimini to have LED overhead dimmable lighting (switched from console)

Fender socks with Princess logo – Grey (each)

Princess S62 Owner’s Manual to be supplied in French language

1Kg Hull/Superstructure gelcoat
Spare set of anodes (hull, trim tab, bow thrusters and hydraulic platform)
